2N IP Style User Manual

2N TELEKOMUNIKACE a.s., www.2n.cz 68/105
Tip
To accelerate access card reading, you are recommended to select the
card types used by the user in the module settings.
Caution
supports connection of just one Bluetooth module. If 2N IP Style
®
connected, multiple Bluetooth modules may result in a undesired
behavior.
Bluetooth Reader Module
The Bluetooth reader ( ) is one of the 2N IP Verso system elements Part No. 9155046
®
and helps authenticate users and subsequently open doors using Android and iOS
based smartphones via the Bluetooth protocol 4.0, thus replacing the RFID cards.
Make sure that 2N Mobile Key is installed available from and to
®
Google Play Appstore
make authentication work properly. The application requires phones with Android OS
6 and higher and iOS 12 and higher.
The module contains two bus connectors.2N IP Style
®
These two connectors are fully interchangeable and can be used either as inputs
from the basic unit or outputs to other modules.
If this module is the last one on the bus, one of the connectors remains
unconnected.
The module package includes a 220 mm long interconnecting cable.
The module uses the 2.4 GHz frequency.
IDs from the following Bluetooth 4.0 supporting smartphones can be read:
Android 6 and higher
iOS 12 and higher

2N IP Style Specifications

General

Tamper Switch	Yes
Power Supply	12V DC
Ingress Protection	IP65
Inputs	2
Operating Voltage	12V DC
Speaker Impedance	8 Ohm
