2N IP Style User Manual

2N TELEKOMUNIKACE a.s., www.2n.cz 71/105
RELAY1 RELAY1 terminals with accessible 30 V / 1 A AC/DC NO/NC contact
RELAY2 RELAY2 terminals with accessible 30 V / 1 A AC/DC NO/NC contact
IN1 IN1 terminals for input in passive / active mode ( 30 V to +30 V DC)−
OFF = open contact or U > 1.5 V
IN
ON = closed contact or U < 1.5 V
IN
IN2 IN2 terminals for input in passive / active mode ( 30 V to +30 V DC)−
OFF = open contact or U > 1.5 V
IN
ON = closed contact or U < 1.5 V
IN
TAMPER Tamper switch (9155038) input

2N IP Style Specifications

General

Tamper Switch	Yes
Power Supply	12V DC
Ingress Protection	IP65
Inputs	2
Operating Voltage	12V DC
Speaker Impedance	8 Ohm
