2N IP Style User Manual

2N TELEKOMUNIKACE a.s., www.2n.cz 72/105
Wiegand Module
The Wiegand module ( ) is one of the 2N IP Verso system elements Part No. 9155037
®
and is used for connecting an external Wiegand device (RFID card reader, fingerprint
/ biometric data scanner) and/or connecting the intercom to an external security
exchange. All the inputs and outputs are galvanically isolated from the intercom with
the insulation strength of 500 V DC. It is necessary to feed +U IN on Wiegand OUT
from the Control Panel.
Reader – connects an external Wiegand-supporting reader. The reader sends
information on the intercom card number.
Control Panel – used for connection to the security PBX / access system to
which the intercom sends the card number information.
The module contains two bus connectors.2N IP Style
®
These two connectors are fully interchangeable and can be used either as inputs
from the basic unit or outputs to other modules.
If this module is the last one on the bus, one of the connectors remains
unconnected.
The module package includes a 80 mm long interconnecting cable.
Configure the module name in the Module name parameter in the Hardware /
Extending modules menu.
The LED IN input is addressed as follows: , e.g. <module_name>.<input1>
module2.input1.
The Tamper input is addressed as follows: , e.g. <module_name>.<tamper>
module2.tamper.
The LED OUT output (negated) is addressed as follows: <module_name>.
, e.g. module2.output1.<output1>
