Reader W0 W1 GNDIN, IN, 1 Isolated 2-wire WIEGAND IN
LED OUT Isolated open LED OUT switched against GND (up to 24 1
V / 50 mA)
Control
Panel
+U IN +U input (5 to 15 V DC) for WIEGAND OUT power supply
W0 W1 GNDOUT, OUT,
2
Isolated 2-wire WIEGAND OUT
LED IN (negated) Isolated input for open LED IN, input activated by GND
2
connection
LED IN Isolated input for open LED IN, input activated by +U
connection
 G +U WIEGAND OUT active supply LED indicatorIN
 TAMPER Tamper switch (Part No. ) input9155038

2N IP Style Specifications

General

Tamper Switch	Yes
Power Supply	12V DC
Ingress Protection	IP65
Inputs	2
Operating Voltage	12V DC
Speaker Impedance	8 Ohm
