Specifications:
Passive switch: NO and NC contacts, up to 30 V / 1 A AC / DC
Switched output:
Where the security relay is fed from the intercom, 9 to 13 V DC is available on
the output depending on the power supply (PoE: 9 V; adapter: source voltage of
minus 1 V) / 400 mA DC.
Where the security relay is fed from an external power supply, 12 V / 700 mA DC
is available on the output.
Dimensions: (56 x 31 x 24) mm
Weight: 20 g
Installation:
Install onto a two-wire cable between the intercom and the 2N Security Relay
®
electric lock inside the area to be secured (typically behind the door). The device is
powered and controlled via this two-wire cable and can thus be added to an existing
installation. Thanks to its compact dimensions, the device can be installed into a
standard mounting box.
Connection:
Connect to the intercom as follows:2N Security Relay
®
To the active output (OUT1)
Connect the electric lock to output as follows:2N Security Relay
®
To the switched output
To the passive output in series with the external power supply
The device also supports a Departure button connected between the ‘PB’ and ‘-
HeliosIP / IP Intercom terminals. Press the Departure button to activate the output for
5 seconds.
Status Signaling:
Green LED Red LED Status
flashing off Operational mode
