Green LED Red LED Status
on off Activated output
flashing flashing Programming mode – waiting for initialization
on flashing Error – wrong code received
Configuration:
Connect to the properly set Security intercom output. Refer to the 2N Security Relay
®
for details. Make sure that one LED at least Configuration Manual for 2N IP Intercoms
is on or flashing.
Press and hold the Reset button for 5 seconds to put the device in 2N Security Relay
®
the programming mode (both the red and green LEDs are flashing).
Activate the switch output using the keypad, phone, etc. The first code sent from the
intercom will be stored in the memory and considered valid. After code initialization,
will pass into the operational mode (the green LED is flashing).2N Security Relay
®
