5-1
5 n Repeater Mode Configuratio
Rep iguration Example
N
eater Mode Conf
etwork Requirements
As shown in Figure 5-1:
AP1 connects to the wired network. The AP acting as a repeater needs to set up a WDS link with AP 1.
s
z
z
WDS link between AP 1 and the repeater must be the same as that of the
nel.
uration procedure, refer to Configuration
At the same time, the repeater needs to provide wireless access service for clients.
To atisfy the requirements above:
z Use the 802.11n (2.4GHz) radio to set up a WDS link between AP 1 and the repeater.
Use the 802.11n (2.4GHz) radio to connect clients to the repeater.
The channel of the
access service. In this example, channel 11 in 802.11n (2.4GHz) radio mode is used as the
working chan
z Configure WDS on AP 1. For the detailed config
edure
proc .
z Configure WDS and access service on the repeater.
Figure 5-1 Network diagram for repeater mode configuration
AP 1
Client 1
Repeater
LAN Segmen t
Channel 11
802.11n
Channel 11
802.11n
Channel 11
802.11n
Client 2
C i
ntry/Region Code from the navigation tree to enter the page for setting a
onf guration procedure
Perform the following configurations on the repeater:
1) Select a correct country/region code
Select Advanced > Cou
country/region code, as shown in Figure 3-2.
2) Configur
ing WDS
Select Wireless Service > WDS from the navigation tree to enter the WDS Setup page shown in
Figure 5-2
.
