3-5
s office and research, and enable the radios.
z Click Apply.
# Bind the corresponding radio to wireless services office and research respectively, enable the
wireless service
4) Verify the configuration
Select Summary > Client from the navigation tree, and enter the page shown in Figure 3-10 to view the
online clients.
Figure 3-10 View the online clients
On this page, you can see that client 2, which accesses the SSID office, is in VLAN 3, while client 1,
each other.
which accesses the SSID research, is in VLAN 2. Because the two clients are in different VLANs, they
cannot access
Configuration guidelines
When satisfied with the configuration Save Configuration to File to ensure it is not lost when the Access
PSK
N
Point restarts.
Authentication Configuration Example
etwork requirements
As shown in Figure 3-11, it is required that the client acce
authentication. The PSK key configuration on the client is the same
Figure 3-11 Network diagram for PSK authentication configuration
ss the wireless network by passing PSK
as that on the AP, that is, 12345678.
IP network
ch
FAT AP
L2 swit
Client
C
n code
/Region Code from the navigation tree to enter the page for setting a
onfiguration procedure
1) Select a correct country/regio
Select Advanced > Country
country/region code, as shown in Figure 3-2.
2) Configure a wireless service
# Create a wireless service.
Select Wireless Service > Access Service from the navigation tree, and click New to enter the page
for creating a wireless service, as shown in Figure 3-12
:
