3D Systems CubeX User Manual

INSTALLING THE NEW PRINT TIP
1
Feed the print tip wires up through the print jet carriage and plug them into the Print Jet sensor board.
2
Slide the new print tip into the print jet and turn it until the print tip wires are orientated to travel straight up
to the Print Jet sensor board.
LEVELING THE PRINT TIPS FOR CUBEX DUO/TRIO
!
*/
For a single print jet please see Fastening the print tip on a CubeX.
1
Power on the CubeX printer.
2
To clean the nozzles for levelling, put the CubeX printer into PJ-Control mode. Heat all of the print jets
EXCEPT for the new one to 230° and clean of any plastic debris with pliers. Allow the Print Jets to cool
down.

3D Systems CubeX Specifications

General

Printing colors	White
Print technology	-
Printing material	ABS, Polylactic acid (PLA)
Maximum build speed	15 mm³/s
Layer thickness (max)	0.100 mm
Layer thickness (min)	- mm
Number of print heads	1
Maximum build size (WxDxH)	275 x 265 x 240 mm
Product color	Gray
Viewing window	Yes
Maximum extruder tip temperature	280 °C
Ethernet LAN	No
AC input voltage	110-240 V

Weight and Dimensions

Width	515 mm
Height	598 mm
Weight	36000 g
