8
With the print tips levelled you can now turn on the CubeX printer and set the print tip offsets.
SETTING PRINT TIP OFFSETS
See the CubeX user guide for instructions on how to set your print tip offsets.
Download the CubeX Duo calibration file
Download the CubeX Trio calibration file
FASTENING THE PRINT TIP ON A CUBEX
!
A CubeX with a single print jet does not have a second or third nozzle to reference the print tip level.
Instead you have to use the CubeX wiping stick.
1
Power on the CubeX printer.
2
Put the CubeX into manual move.
3
Raise the print pad until it is approximately 5mm away from the print tip.
4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the 3D Systems CubeX and is the answer not in the manual?

3D Systems CubeX Specifications

General IconGeneral
Printing colorsWhite
Print technology-
Printing materialABS, Polylactic acid (PLA)
Maximum build speed15 mm³/s
Layer thickness (max)0.100 mm
Layer thickness (min)- mm
Number of print heads1
Maximum build size (WxDxH)275 x 265 x 240 mm
Product colorGray
Viewing windowYes
Maximum extruder tip temperature280 °C
Ethernet LANNo
AC input voltage110-240 V
Weight and Dimensions IconWeight and Dimensions
Width515 mm
Height598 mm
Weight36000 g
