Pannoramic 1000 1.2 – User’s Guide 3 Preparing Slides and Magazines
3 Preparing Slides and Magazines
You can use both standard and large slides and cover slips that meet the following specifications:
Slides Cover slips
Length 75.0 to 76.0 mm max. 50 mm
Width (standard slide) 25.0 to 26.0 mm max. 24 mm (recommended: 22 mm)
Width (large slide) 51.0 to 52.0 mm max. 50 mm
Thickness 0.90 to 1.2 mm No. 1 and No. 1.5 (0.13 to 0.16 mm and 0.16 to 0.19 mm)
Corners 45° beveled corners
Edges Ground or cut
Warning!
Always wear personal protective equipment (safety goggles, gloves and
coat) when working with bio-hazardous material or slides.
Warning!
Do not use a slide when it is broken or its edges are not properly cut or
grounded. Using such slides can lead to injury.
Warning!
Ensure that no part of the mounted coverslip protrudes from the edges
of the slide.
Use slides with completely dried embedding medium only. Otherwise,
the coverslip can be shifted that makes slide insertion less reliable. Not
completely dried embedding might also influence the operation of
objectives and other device parts.
March 19, 2019 – Rev. 2 3DHISTECH Ltd. 24(78)
