Pannoramic 1000 1.2 – User’s Guide 3 Preparing Slides and Magazines
Caution!
Do NOT scratch any circular marker onto the glass surface of a slide,
use a soft tip pen instead for marking area of interest.
3.1 Affixing Barcode Stickers to Slides
This section describes how to affix barcode stickers to slides. Barcodes enable virtual slide
identification.
Caution!
Ensure that a marginal space of 1-2 mm remains on all sides between
the sticker and the label area outer limits. It is vital for barcode
identification. Do not let barcode sticker protrude from slide edges, or
stick on the coverslip surface (3).
The thickness of the barcode sticker on the slide must not exceed 0.4
mm! Do not stick more than four barcode stickers over each other and
the overall thickness must must be kept below 1.65 mm (including the
barcodes and the slide).
Figure 7 – Standard and large format slides with barcode stickers
March 19, 2019 – Rev. 2 3DHISTECH Ltd. 25(78)
