3M™ Multi-Touch Chassis Display User Guide 17
3M Touch Systems, Inc. Proprietary Information – TSD-39373B
Supported Video Display Modes and Refresh Rates
Your video card should support one of the display modes specified below. If you select
an unsupported video mode, the display may stop working or display unsatisfactory
picture quality.
Display Mode Refresh Rate (Hz)
640 x 480 60
800 x 600 60
1024 x 768 60
1152 x 864 70
1280 x 720 60
1280 x 768 60
1280 x 960 60
1280 x 1024 60
1360 x 768 60
1600 x 1200 60
1680 x 1050 60
1920 x 1080 60
Configuring the Display Settings
After you connect your Multi-Touch Chassis Display and turn on your computer, you
may need to configure one or more of these display settings. The ideal setting for the
Multi-Touch Chassis Display is as follows:
Display mode (also called desktop area or video native resolution) 1920 x 1080
Refresh rate (also called vertical scan rate or vertical sync) 60 Hz
Color depth (also called color palette or number of colors) at least 16-bit (high color)
Adjusting the Multi-Touch Chassis Video Display
This section provides guidelines for adjusting the video display and using the display
controls to adjust the image to your liking. The controls for adjusting the video display
are located on the back of the Multi-Touch Chassis Display. These buttons let you
display the on-screen menu and adjust the phase, image position, contrast, and brightness.
Before you make any adjustments:
• Be sure to adjust the controls in your normal lighting conditions.
• Display a test image or pattern whenever you adjust the video.
