36 3M™ Multi-Touch Chassis Display User Guide
3M Touch Systems, Inc. Proprietary Information – TSD-39373B
Set Feature - Reset
This is a request to perform a controller reset. Soft resets are automatic after any block
parameter changes.
Table 11. Reset - Setup Stage
Offset Field Size Value Description
0 bmRequestType 1 0x21 Class,H2D,Interface
1 bRequest 1 0x09 Set Report
2 wValue 2 0x0303 msb=03=Feature
lsb=03= Feature Report ID
4 wIndex 2 0 Always 0
6 wLength 2 8 Always 8
Table 12. Reset – Data Stage
Offset Field Size Value Description
0 Report ID 1 0x03 Feature Report ID
1 Report Subtype 1 0x07 Indicates a reset request
2 bResetType 1 0x01
0x02
Soft Reset
Hard Reset
3--7 5 0 Not used
A Hard Reset will cause the controller to re-enumerate.
In the case of a Soft Reset, after sending the command, the controller will acknowledge
(ACK) the transfer, but the command will not yet be completed. Before sending any other
commands, the host should poll with GetStatus until the command status field returns
“Soft Reset Occurred,” “Command Complete,” or “Fail”. Any timeout for this status
polling should be 2 seconds minimum.
Set Feature –Restore Defaults
This is a request to restore parameter defaults.
Table 13. Restore Defaults -- Setup Stage
Offset Field Size Value Description
0 bmRequestType 1 0x21 Class,H2D,Interface
1 bRequest 1 0x09 Set Report
2 wValue 2 0x0303 msb=03=Feature
lsb=03= Feature Report ID
4 wIndex 2 0 Always 0
6 wLength 2 8 Always 8
