38 3M™ Multi-Touch Chassis Display User Guide

3M Touch Systems, Inc. Proprietary Information – TSD-39373B

Table 16. Touch Report Structure

Offset Field Size Value Description

0 Status 6 0xXX 0x00 Report not valid

0x04 Not touching

0x07 Touching

1 Touch ID 1 0-255 Touch thread ID number

2 X lsb 1 0xXX X ( 0-7FFF)

3 X msb 1 0xXX

4 Y lsb 1 0xXX Y ( 0-7FFF)

5 Y msb 1 0xXX

6 Width lsb 1 0xXX Width ( 0-7FFF)

7 Width msb 1 0xXX

8 Height lsb 1 0xXX Height ( 0-7FFF)

9 Height msb 1 0xXX
