3M Dynatel 955 User Manual

Operation
Section 1
Page 13
Voltage
RED to RING
BLACK to TIP
GREEN to GROUNDED SHIELD
Hookup:
R
B
G
Voltage
On
Reset
You can continue to check
different configurations by
pressing the
✽ and # keys.
Disregard this step
if the unit is on.
Show ring–ground
VDC results
Show ring-ground
VAC results
Turn unit on.
Run test, show
tip-ring VDC
results
End
of
Test
Show tip-ground VDC
results
Show tip-ground VAC
results
Show tip-ring VAC
results
Show ring-ground
VDC results
Press any test key to get out of
the test program.
OR
OR
