Special Applications
Section 2
Page 63
Counting Load Coils
1
RED to RING
BLACK to TIP
Hookup:
R
B
On
Reset
Opens
Turn unit on.
Normal, Special,
Split Locate, Load
Coil Count
Move ✽ to select test
type– Load Coil Count
Results of load coil
count
Disregard this step
if the unit is on.
End
of
Test
The load coil count takes 1.5
minutes to complete. When
the unit displays the results,
you can press the
✽
(star)
key to repeat the test.
OR
OR
1
Early software versions of the 900 Series/900M Series test sets
are not equipped to count load coils. To determine if your set is
equipped to do load coil counts, press the OPENS key. If the
set is so equipped, the menu includes a “load coil count”
option.
