Care & Maintenance
Section 4
Page 85Page 85
CHECK RFL FUNCTION, continued
You can press # to repeat the
test with the most commonly
used cable gauges.
End
of
Test
“PLEASE WAIT” while
unit continues RFL
measurement
Accuracy results
DTF=1210 ft/369 m
STF=10890 ft/3312 m
DTS=12100 ft/3680 m
DTS results:
DTS=12100 ft/3680 m
Min Max
Fault Resistance: 995k 1M
Strap Checks:
RED to GREEN 193 207
RED to YELLOW 94 104
Self Test:
Fault Magnitude Straps Check Table
AWG Min Max Min Max Min Max
19 11910 12290 1170 1230 10730 11070
22 5986 6171 592 613 5393 5559
24 3755 3871 371 385 3383 3488
25 2970 3063 293 305 2676 2759
26 2347 2420 232 240 2114 2180
28 1479 1526 146 152 1332 1375
Ohms 99.3 102.5 9.8 10.2 89.5 92.3
English RFL Self Test
70°F
*
*
*
*
DTS DTF STF
* Disregard the ‘move closer to fault...’ message for the self-test.
