CHAPTER 1
INTRODUCTION
This chapter describes the 3M Scott Vision C5 full facepiece and its major components.
Before You Begin
Carefully read “Safety Information” on page 7 before beginning any of the procedures in this User Instruction.
Overview
The Vision C5 full facepiece, when combined with an appropriate respiratory protection system, provides respiratory
protection to an individual when entering, working in, or exiting a hazardous atmosphere. This equipment is designed
to withstand exposure to certain environmental conditions as defined by the applicable approvals.
Facepiece Components
The Vision C5 facepiece consists of the components shown in Figure 1-1.
Figure 1-1 3M Scott Vision C5 full facepiece
Head Harness
Nosecup with
inhalation valves
Lens
(Fenestra)
Facepiece Docking Port
Voicemitters
Lens Frame
(Bezel)
