Please read these instructions in conjunction with the
appropriate 3M™ Filter Leaflet and with the 3M™ Face Piece
Reference Leaflet where you will find information on:
•
Approved combinations of 3M™ filters
•
Accessories
•
Spare parts
SYSTEM DESCRIPTION
These products meet the requirements of EN 140:1998 and
AS/NZS 1716:2012, re-usable half masks and should be
used in combination with a pair of approved 3M filters (see
Reference Leaflet) to form a filtering apparatus for respiratory
protection.
Such apparatus is designed to remove potentially harmful
particulates from the surrounding atmosphere.
^
Particular attention should be given to warning
statements where indicated.
^WARNINGS AND LIMITATIONS
•
Proper selection, training, use and appropriate
maintenance are essential in order for the product to
help protect the wearer from certain airborne
contaminants. Failure to follow all instructions on the
use of these respiratory protection products and/or
failure to properly wear the complete product during all
periods of exposure may adversely affect the wearer’s
health, lead to severe or life threatening illness or
permanent disability.
•
Always be sure that the complete product is:
- Suitable for the application;
- Fitted correctly;
- Worn during all periods of exposure;
- Replaced when necessary.
•
For suitability and proper use follow local regulations, refer
to all information supplied or contact an occupational
hygienist, safety professional or 3M representative on the
Tech Assist Helpline 3M Australia 1800 024 464, 3M New
Zealand 0800 364 357.
•
Before use, the wearer must be trained in use of the
complete product in accordance with applicable Health and
Safety standards/guidance.
•
Only use with the 3M™ Filters and spares and accessories
listed and within the usage conditions given in the Technical
Specification.
•
Never modify or alter this product. Replace parts only with
original 3M spare parts.
•
Maintenance, servicing and repair must only be carried out
by properly trained personnel.
•
General inspection must be carried out before use or
monthly if not in regular use. See Inspection procedures for
specific details.
•
Do not use in atmospheres containing less than 19.5%
oxygen. (3M definition. Individual countries may apply their
own limits on oxygen deficiency. Seek advice if in doubt).
•
Do not use in oxygen-enriched atmospheres.
•
Do not use for respiratory protection against atmospheric
contaminants/concentrations which are unknown or
immediately dangerous to life and health (IDLH) or against
contaminants/concentrations which generate high heats of
reaction with chemical filters.
•
Select and wear appropriate protection when exposed
to sparks and/or flames.
•
In case of intended use in explosive atmospheres, contact
3M Technical Service.
•
Do not use with beards or other facial hair that may
inhibit contact between the face and the product thus
preventing a good seal.
•
Leave the contaminated area immediately if:
a) Breathing becomes difficult or increased breathing
resistance occurs.
b) Dizziness or other distress occurs.
c) You smell or taste contaminants or irritation occurs.
d) Airflow to the face piece decreases or stops.
e) Any part of the system becomes damaged.
•
National regulations may impose specific limitations on the
use of filters depending on the filter class and the facepiece
used. Use of any 3M™ Face piece / Filter combination
should be in accordance with applicable Health and Safety
standards, AS/NZS 1715, Respiratory Selection Tables or in
accordance with the recommendations of an Occupational
Hygienist.
•
Materials which may come into contact with the wearer's
skin are not known to cause allergic reactions to the majority
of individuals.
•
These products do not contain components made from
natural rubber latex.
PREPARATION FOR USE
UNPACKING
Check apparatus is complete, undamaged and correctly
assembled
Inspection
The following inspection procedure is recommended before
use:
1. Check the face piece for cracks, tears and dirt. Be certain
the face piece, especially the face seal area, is not distorted.
The material must be pliable – not stiff.
2. Examine the in
halation valves for cracks or tears. Lift
valves and inspect valve seat for dirt or cracks.
3. Ensure that the head straps are intact and have good
elasticity.
4. Examine all plastic parts for signs of cracks or fatigue.
5. Remove the exhalation valve cover and examine the
exhalation valve and valve seat for signs of dirt, distortion,
cracks or tears. Replace the exhalation valve cover.
6. Examine filter sealing area (Figure 1) for distortion or
dirt/particulate that could prevent filters from sealing to the
respirator.
7. If present, ensure the speaking diaphragm is securely
inserted in the facepiece and the speaking diaphragm film is
intact.
ASSEMBLY INSTRUCTIONS
See appropriate user instructions for assembly instructions
(eg. 3M filter leaflet)
FITTING INSTRUCTIONS
1. Adjust head cradle size as needed to fit comfortably on
head.
2. Place the respirator over the nose and mouth, fitting it
comfortably on the bridge of the nose, then pull the head
harness over the crown of the head. See Fig. 2.
3. Take a bottom strap in each hand, place the straps at the
back of the neck and hook the straps together. See Fig. 3.
4. Pull the ends of the straps to adjust the tightness,
beginning with the adjustment points on the head cradle and
then moving to the adjustment points at the back of the neck.
Do not over-tighten to the point where the faceseal becomes
deformed. Head Harness/neck strap tension may be
decreased by squeezing the buckle tabs on the harness.
5. Perform a positive and/or negative pressure user seal
check each time the respirator is donned.
Seal Check
Negative Pressure User Seal Check
Lightly press the seal check button and inhale gently (Figure
4). If you feel the facepiece collapse slightly and pull closer to
your face with no leaks between the face and facepiece, a
proper seal has been obtained.
If faceseal air leakage is detected, reposition respirator on
face and/or readjust tension of straps to eliminate air leakage.
Repeat the user seal check until a proper seal is obtained.
Positive Pressure User Seal Check
Cover the opening in exhalation valve cover with hand and
exhale gently (Figure 5). If facepiece bulges slightly and no
air leaks are detected between your face and facepiece, a
proper seal has been obtained.
If faceseal air leakage is detected, reposition respirator on
face and/or readjust tension of straps to eliminate air leakage.
Repeat the user seal check until a
proper seal is obtained.
If you CANNOT achieve a proper fit DO NOT enter the
hazardous area.
Fit Testing
It is recommended that wearers should be fit tested in
accordance with AS/NZS 1715.
For information regarding fit testing procedures, please
contact 3M.
HF-800SD only
Please use a HF-800-03 Quantitative Fit Test Adapter if
performing a quantitative fit test.
Qualitative Fit with the 3M™ Qualitative Fit Test Apparatus
FT-10 or FT-30 can be conducted using any of the compliant
particulate filters.
DOFFING
Do not remove the face piece, or filters until you have
vacated the contaminated area.
1. Release the tension on the head straps.
2. Carefully lift face piece off the face and remove the
respirator by lifting up and away from the face.
Replacement Parts Instructions
Respirator components, especially exhalation and inhalation
valves should be discarded and replaced with new parts
when damaged If disposal of parts is required this should be
undertaken in accordance with local health and safety and
environmental regulations.
3M™ Head Harness Assembly & Valve Cover Replacement
1. Remove Head Harness Assembly by using your thumb to
pull down on the head harness assembly until it clears the
bottom of the facepiece, then lift the head harness assembly
away from the facepiece. (Figure 6).
2. Replace Head Harness Assembly by positioning the peg
on the facepiece into the notch at the top of the head harness
assembly (Fig. 7 - 1). Press the bottom of the head harness
assembly into the facepiece (Fig.7 - 2). When properly
engaged, an audible snap should be heard.
Exhalation Valve Replacement
1. Remove head harness as described in the previous
section.
2. Remove the exhalation valve from valve seat by grasping
the valve and pulling the valve stem out of the valve seat
(Figure 8).
3. Replace valve by aligning the valve stem with the hole in
the centre of the valve seat. Press the valve post through the
hole in the valve seat. Be certain valve is fully engaged
through valve post and lays flat against the valve seat.
4. Replace Head Harness Assembly as described above.
NOTE
Conduct a negative pressure user seal check to ensure
exhalation valve is functioning properly.
Inhalation Valve Replacement
The inhalation valve is located on the inside of the facepiece
above the exhalation valve. The inhalation valve should be
inspected before each respirator use and during cleaning.
Replace whenever valve is damaged or lost.
1. Remove existing valve(s) by grasping valve and pulling
valve off the centre post.
2. Replace valve by aligning the valve stem with the hole in
the centre of the valve seat (Fig.9). Press the valve post
through the hole in the valve seat (Fig. 10). Be certain
valve(s) is fully engaged through valve post(s) and lays flat.
Speaking Diaphragm Removal/Replacement
To Remove: Turn speaking diaphragm a quarter turn
counter-clockwise, and push the speaking diaphragm inward
from the outside of the facepiece. To install: Align the
speaking diaphragm with the guides on the facepiece, and
turn clockwise a quarter turn.
CLEANING AND DISINFECTION
Cleaning is recommended after each use.
To clean the respirator, the 3M™ 504 Wipe should be used
to wipe the face seal of the product.
Remove filters.
The head harness, exhalation valve cover, exhalation valve,
inhalation valves and speaking diaphragm (if present) can
also be disassembled if necessary.
Clean parts (excluding filters) by immersing in warm cleaning
solution (water temperature not to exceed 50°C), scrub with
soft brush until clean.
Add neutral detergent if necessary.
Disinfect respirator by soaking in a solution of quaternary
ammonia disinfectant or sodium hypochlorite (30ml/7.5l) or
other disinfectant.
Rinse in clean, warm water and air dry at room temperature
in a non-contaminated atmosphere.
Do not reassemble parts until facepiece is completely dry.
Ensure the cartridge/filter connection area is free of debris
(Fig. 1).
Use a cloth or soft brush to reach this area and/or move
facepiece back and forth quickly while immersed in cleaning
solution.
A respirator washer can be used to clean the HF-800 Series
respirator.
Respirator washers have a rack designed to hold the
respirator in place during washing.
DO NOT use a washing machine, which allows the
respirators to tumble while being washed.
This could damage the respirator.
Water temperature should not exceed 50°C.
CAUTION
Do not use cleaners containing lanolin or other oils on these
products.
STORAGE AND TRANSPORTATION
These products should be stored in the packaging provided
in dry, clean conditions away from sources of high
temperature and petrol and solvent vapours. The original
packaging is suitable for transporting the product. Store in
accordance with manufacturer’s instructions, see packaging.
When stored as stated, the expected shelf life of the product
is 5 years from date of manufacture. Do not use the product
after the expiration date.
[
End of Shelf Life. Date format - mm/yyyy
\
Temperature Range
,
Maximum Relative Humidity
:
Name and address of Manufacturer
J
Dispose in accordance with local regulations
The date of manufacture can be established by examining
the date clock on the inside of the facepiece. See Fig. 11.
The inner segment will display the year, and the arrow will
point to the month of manufacture in the outer segment. The
example shows 01/12/2019 - 31/12/2019. The head harness
assembly and filter holder are also marked with a date wheel
indicating their month and year of manufacture
K
Packaging not suitable for food contact.
TECHNICAL SPECIFICATION
Respiratory Protection
ITA189714/0819 © 3M
3M Nederland B.V.
Molengraaffsingel 29
2629 JD Delft
+31 (0)15 7822406
3M Svenska AB
Bollstanäsvägen 3
191 89 Sollentuna
+46 8 92 21 00
3M (Denmark) a/s
Hannemanns Allé 53
DK 2300 København S
+45 43480100
3M Norge AS
Tærudgata 16
Postboks 300, 2001 Lillestrøm.
Tlf: 06384
Suomen 3M Oy
PL 600 (Keilaranta 6)
02151 Espoo
p. +358 9 525 21
Tengiliður á Íslandi:
Hannemanns Allé 53
DK 2300 København S
+45 43480100
3M Italia srl
Via Norberto Bobbio 21
20096 Pioltello (MI)
+39 02 70351
3M España,S.L.
Juan Ignacio Luca de Tena,
19-25
28027 Madrid
+34 91 321 62 81
3M Österreich GmbH
Kranichberggasse 4
1120 Wien
+43 1 86686 0
3M Gulf Ltd.
P.O. Box 20191
Building 11, Third Floor, Dubai
Internet City, Deira
+ 971 4 367 0777
3M United Kingdom PLC
3M Centre, Cain Road
Bracknell, RG12 8HT
0870 60 800 60
3M Egypt Trading Ltd.
Sofitel Tower, 19th Floor,
Corniche el-Nil St.
Maadi, Cairo
+202 2525 9007
3M Deutschland GmbH
Carl-Schurz-Str. 1
41453 Neuss
+49 2131 14 26 04
3M Ireland
The Iveagh Building, The Park
Carrickmines, Dublin 18
1 800 320 500
3M South Africa
146a Kelvin Drive, Woodmead
Sandton 2128, Johannesburg
+27 11 806 2230
3M France
Bd de l'Oise
95006 Cergy Pontoise Cedex
+33 1 30 31 61 61
3M Belgium bvba/sprl
Hermeslaan 7
1831 Diegem
+32 2 722 51 11
3M (Schweiz) GmbH,
Eggstrasse 93, Postfach,
8803 Rüschlikon, Switzerand,
Tel: 044 724 90 90.
3M Hellas MEPE
Κηφισίας 20,
151 25, Μαρούσι, Αθήνα,
Ελλάδα
+30 210 68 85 300
3M España, S.L., Sucursal
em Portugal, Edifício Office
Oriente
Rua do Mar da China, nº 3 - 3º
Piso A.
1990-138 Lisboa.
+351 21 313 4500
3M Poland Sp. z o.o.
Aleja Katowicka 117, Kajetany
K / Warszawy
05-830 Nadarzyn
+48 22 739 60 00
3M Hungária Kft.
Inforpark E Épület, 1117
Budapest
Neumann János utca 1/E
+36 1 270 7777
3M Česko, s.r.o.
V Parku 2343/24
148 00 Praha 4
+420 261 380 111
3M Australia Pty Limited
1 Rivett Road, North Ryde
N.S.W. 2113
+61 (1)800 024 464
3М България
Младост 4, бизнес парк
София, сграда 4, етаж 2
1766 София, България
тел: 02/9601911, факс
02/9601926
3M (East) AG Predstavništvo
RS,
Omladinskih brigada 90b,
11070 Beograd.
Tel: +381(0) 11 2209 400.
3M Türkiye
Barbaros Mah. Mor Sümbül
Sok. No:7/3F 27-51
Nidakule Ataşehir Güney
34746 Ataşehir/İstanbul
Telefon: (+90) 216 538 07 77
3М Қазақстан ЖШС
Қазақстан Республикасы,
050051 Алматы қ.,
«Көктем-2»
бизнес-орталығы,
Фонвизин к-сі 17А, 3-ші
қабатты,
тел.: +7 727 333 0000,
факс: +7 727 333 0001
3M New Zealand Limited
94 Apollo Drive, Rosedale
AUCKLAND 0632, New
Zealand
+64 (0)800 364 357
3M Lietuva
A. Goštauto g. 40A
LT-03163 Vilnius
+370 5 216 07 80
3M România
Bucharest Business Park, Str.
Menuetului 12, cladirea D,
et.3,
013713 Bucharest
+40 21 2028000
3М Україна
Бізнес-центр "Горизонт
Парк", 7 пов., вул. М.
Амосова, 12, Київ
03680, Київ, Україна
тел: +38 (044) 490 57 77.
3М Россия
108811, г. Москва, п. Московский,
Киевское ш., 22-й км,
домовл. 6, стр. 1
+7 495 784 74 74
Представительство 3М в
Беларуси, Бизнес-центр
"Омега Тауэр", 5й этаж
Пр-т Дзержинского, 57
220089 а/я 23 Минск,
Беларусь
+375 17 372 70 06
3M (East) AG
"BRIDGE Plaza" 4th floor, 12
Bakikhanov street
Baku AZ 1065
+994 12 404 5050
3M (EAST) AG
PODRUŽNICA RH
Avenija Većeslava Holjevca 40
10010 Zagreb
+385 1 2499 750
3M Latvija SIA,
K. Ulmaņa gatve 5,
Rīga, LV-1004
+371 67 066 120
3M Eesti OÜ
Pärnu mnt. 158
11317 Tallinn
+372 6 115 900
3M Slovensko s.r.o.
Polus Tower II, Vajnorská
100/B,
831 04 Bratislava, Slovensko
Tel: +421 249 105 211
3M (East) AG
Podružnica v Ljubljani
Cesta v Gorice 8, SI-1000
Ljubljana
+386 1 2003 630
3M מ״עב לארשי
91 םידוהיה תנידמ בוחר
46120 הילצרה - 2042 .ד׃ת
+972 9 961 5000
3M United Kingdom PLC, 3M Centre, Cain Road, Bracknell, Berkshire, RG12 8HT, UK
3M Wroclaw Sp. z o.o, Kowalska 143, 51-424 Wroclaw, Poland
To Next Page
Loading...
