T11 Spec（LCD Monitor）
2.4Ghz Wireless Microscope Anyty TV Model
Spec of the LCD Monitor
※Please refer to the detail of the specifications of the PC model for the specifications of the main
body of Anyty microscope
※The magnification will be based on the size of images which are displayed on 15 inches monitor. The
magnification of when it is displayed it with a attached monitor of the TV model will be different.
Thank you for your understanding beforehand.
LCD
3.5 inches TFT LC
Resolution
320ｘ240
Video format
PAL/NTSC
Frequency
2414MHz、2432MHz、2450MHz、2468MHz
Power supply
5VDC
Consumption current（max）
500mA
Charging time
About 3 hours
Working time
Maximum 2 hours
Resolution of still/video
640ｘ480
Movement size
27MB/min
Frame rate
Maximum 30fps
Output signal level
0.91.3VP-P@75ohm
Receiver sensitivity
《-85dbm
External form
100x75x25mm
Weight
140g
Workable temp
-10℃～50℃
Workable humidity
15～85％RH
