3S n8072 - Making Connections

N8072 Cube Network Camera 2 Megapixel + H.264
- 8 -
Making Connections
Before you connect your N8072, please make sure your PC has the LAN port available for
connect to the network.
Follow these instructions to connect the N8072 into your PC and LAN Port.
DESCRIPTION
1.
Micro SD Card Slot
Insert the Micro SD Card here.
2.
LAN/PoE
Connect to 10/100 RJ45 network / PoE here.
3.
POWER
Connect to Power here.
4.
Reset Button
Reset to factory setting
Micro SD Card
N8072 Cube Network Camera is compatible with Micro SD card (Maximum 32GB).
