Figure 2. Points of connection on the full-height controller (top view)
Figure 3. Points of connection on the half-height controller (top view)
Note: If your 9000 series controller does not have the
BBU receptacle, contact technical support for
assistance.
b) BBU receptacle
c) Hole for post
a) Slots on the edge
b) BBU receptacle
c) Hole for post
a) Slots on the edge
