VISIX S-Series Network Camera | USER MANUAL v6.0
10385 Westmoor Drive, Suite 210, Westminster, CO 80021 | www.3xlogic.com | (877) 3XLOGIC
37
Figure 5-10 Motion Detection Settings-Expert
Steps:
(1) Schedule Image Settings, OFF, Auto-Switch and Scheduled-Switch modes are available. If
the schedule image switch mode is enabled, you can configure the detection rule for day and
night separately.
(2) OFF: Disable the day and night switch.
(3) Auto-Switch: Switch the day and night mode according to illumination automatically.
(4) Scheduled-Switch: Switch to the day / night mode according to the configured time. You
need to set the start time and end time.
(5) Select Area from the dropdown list to configure.
(6) Set the sensitivity and percentage values.
(7) Sensitivity: The greater the value is, the easier the alarm will be triggered.
(8) Percentage: When the proportional size of the moving object exceeds the predefined value,
the alarm will be triggered. The smaller the value, the easier the alarm will be triggered.
4. Set the Arming Schedule for Motion Detection.
(1) Click the tab to enter the arming schedule setting interface.
