4B W400 Series User Manual

4B - W4005 BÜHLER ELEVATOR MONITORING SYSTEM R9.6 – 22 May 2020
Page 38 of 48
12.19.13. Belt Alignment Status (same for the Head and Tail)
Value
State Name
Description
0
OK
No misalignment is detected
3
MISALIGNMENT ALARM
Misalignment is detected
1,2 and
4 to 65535
INVALID STATE
Invalid State - System Error Occurred. Contact the
manufacturer
Table 25 – Ethernet –Belt Alignment Status
12.19.14. Temperature Alarm Value [°C]
This field indicates the system alarm temperature value selected by SW1 on the W4005NV46AI /B controller.
The setting affects the alarm level for all the temperature sensors used in the system. The value is in 0.1°C
resolution and must be divided by 10 in the PLC to convert to the °C units.
12.19.15. Temperature Status
Value
State Name
Description
0
NOT USED
Temperature sensor input disabled in settings
1
OK
No Temperature Alarm Detected
2
OPEN CIRCUIT
Open Circuit Alarm Detected
3
SHORT CIRCUIT
Short Circuit Alarm Detected
4
ABSOLUTE ALARM
Absolute Temperature Alarm Detected
7
SENSOR WIRED TO
DISABLED CHANNEL
The temperature input channel has been disabled in the
settings, but a sensor is wired. This is an invalid state
4, 5 and
8 to 65535
INVALID STATE
Invalid State - System Error Occurred. Contact the
manufacturer
Table 26 – Ethernet – Temperature Status
12.19.16. Temperature Value [0.1 °C]
This field returns the current sensor temperature in degrees C. The resolution is 0.1°C and this value must
be divided by 10 in the PLC.
12.19.17. Settings – SW1
This is a BYTE length value. See 10.13.1 - Rotary Switch (SW1) for the decoding information
