Is175 Rev. 240102 - 2 Pag. 29
FUEL LEVEL SENSORS Wiring Schematics
C.N.G. SENSOR
L.P.G. SENSOR
GROUND
GREEN
WHITE
GROUND
GREEN
WHITE
0 ÷ 90 Ohm SENSOR
GREEN
WHITE
A.E.B. level sensors wiring schematic
0 ÷ 90 Ohm Level Sensors Wiring Schematic
