The following Transformer Monitor specific input functions are available:
Input function
Description
64:iOilTp-TR
Oil temperature of the transformer
65:iOilTp-TC
Oil temperature of the tap changer
66:iOilL-TR
Oil level of the transformer
67:iOilL-TC
Oil level of the tap changer
68:iWater
Water in oil content (moisture in oil)
69:iGas
Gas in oil content
71:iCO
CO in oil content
72:iH2
H2 on oil content
73:iWndTp-TR
Winding temperature transformer (directly measured by e.g. a fibre optic
temperature measurement device like the REG-FO
The following Transformer Monitor specific output functions are available:
Output function
Description
19:oOilTp-TR
Oil temperature of the transformer
20:oWindTemp
Winding temperature
Analogue channel function 01:ANA
The input function 01:ANA is always selected when a non-standard measured quantity is
used.
In principle, any arbitrary measured quantity that can be represented as a mA value can be
fed into the controller, processed and displayed.
If necessary, limit values can of course be derived from such 'non-standard inputs' and
output by relay. To do this, please contact the A. Eberle head office by using
+49(0)911/628108-101 or regsys-support@a-eberle.de.
Setup of the analogue channels
Additional Information regarding the analogue channels and the according setup can be
found in the manual of the REG-D(A).
