Winding temperature (Alarm) 5.5.2
Limit value
Defines the switch-on point for the alarm signal.
Setting range: 0...200°C
Switching delay
Defines the switch-on delay for the alarm signal.
Setting range: 0...900 s
Hysteresis
Defines the hysteresis for the switching point.
Setting range: 1...30 K
Winding temperature (Trip) 5.5.3
Limit value
Defines the switch-on point for the alarm signal.
Setting range: 0...200°C
Switching delay
Defines the switch-on delay for the alarm signal.
Setting range: 0...900 s
Hysteresis
Defines the hysteresis for the switching point.
Setting range: 1...30 K
