USER SETTINGS & CONTROL SYSTEM MENUS
TEMPERATURES MENU
Operating Set Point And Differential Adjustment
                





NOTE:               
               

DESCRIPTION/ACTION DISPLAY


Tank Te mperature 120°F
Operating Set Point 120°F
Status: Standby
MEN
UH
ELP
MANUFACTURER / MODEL INFORMATION









Temperatures
Heater Status
Display Settings
Heater Information
Current Fault
SELECT BACK HELP
Main Menu





NOTE:




Operating Set Point 120°F
Differential 8°F
Tank Temperature 120°F
Upper Temperature 122°F
Lower Temperature 118°F
(Heater Regulated to Tank)
Upper Probe Offset 0°F
CHANGE BACK HELP
Temperatures






NOTE:


Operating Set Point 140°F
Differential 8°F
Tank Temperature 120°F
Upper Temperature 122°F
Lower Temperature 118°F
(Heater Regulated to Tank)
Upper Probe Offset 0°F
UPDATE CANCEL
Temperatures
