Chapter 2 – Hardware Information 7
Maker Board UP-CHT01
2.3 List of Switches and Connectors
Please refer to the table below for all of the board’s jumpers that you can configure for
your application
Label
Function
SW1
Power Button Wafer
CN1
RTC Battery
CN6
USB 3.0 Micro Connector
CN7
USB 2.0 1x10P Wafer
CN8
USB Type A Connector 1
CN9
USB Type A Connector 2
CN10
RJ45 LAN Connector
CN11
HDMI Connector
CN12
HAT 40 GPIO Connector
CN14
Reset Pin Header
CN30
DC Jack
CN31
MIPI DSI Connector
CN32
MIPI CSI Connector
CN33
Power Button Wafer
CN34
Update CPLD Header
