Aaeon UP-CHT01 - Reset Pin Header (CN14); DC Jack (CN30)

Chapter 2 – Hardware Information 12
Maker Board UP-CHT01
3
I2C1_SDA
4
+5V
5
I2C1_SCL
6
GND
7
ISH_GPIO0
8
UART_TX
9
GND
10
UART_RX
11
SD2_CMD
12
I2S2_CLK
13
SD2_CLK
14
GND
15
SD2_SD0
16
SD2_SD1
17
+3.3V
18
SD2_SD2
19
SPI2_MOSI
20
GND
21
SPI2_MISO
22
SD2_SD3
23
SPI2_CLK
24
ISH_SPI2_CS0
25
GND
26
ISH_SPI2_CS1
27
I2C0_SDA
28
I2C0_SCL
29
ISH_GPIO2
30
GND
31
ISH_GPIO3
32
PWM0
33
PWM1
34
GND
35
I2S2_FRM
36
GPIO27
37
GPIO13
38
I2S2_RX
39
GND
40
I2S2_TX
2.3.10 Reset Pin Header (CN14)
Pin
Signal
1
PMU_RSTBTN_N
2
GND
2.3.11 DC Jack (CN30)
