Aaeon UP-CHT01 - MIPI CSI Connector (CN32)

Chapter 2 – Hardware Information 14
Maker Board UP-CHT01
13
DDI1_DDC_C_CLK
28
DDI0_AUX_DP
43
GND
14
DDI1_DDC_C_DAT
29
DDI0_AUX_DN
15
GND
30
GND
2.3.13 MIPI CSI Connector (CN32)
Pin
Signal
Pin
Signal
1
GND
13
GND
2
MCSI_1_DATA1_DN
14
CAM_MCLK
3
MCSI_1_DATA1_DP
15
GND
4
GND
16
I2C2_SOC_SCL
5
MCSI_1_CLK_DN
17
I2C2_SOC_SDA
6
MCSI_1_CLK_DP
18
CAM_RST_N
7
GND
19
FLASH_RESET_N
8
MCSI_1_DATA0_DN
20
+2.8V
9
MCSI_1_DATA0_DP
21
GND_CAM
10
GND
22
GND
11
+1.2V
23
GND
12
+1.8V
