Aalborg DPC - APPENDIX II: DIMENSIONAL DRAWINGS

118
APPENDIX II: DIMENSIONAL DRAWINGS
ABCD
DPC04 / 07
3.68" (93.4 mm) 4.58" (116.2 mm) 0.34" (8.5 mm) 10-32 UNF
DPC14
3.85" (97.7 mm) 4.84" (122.8 mm) 0.42" (10.7 mm) 1/4 NPT
DPC17
3.66" (92.9 mm) 4.40" (111.8 mm) 0.35" (8.9 mm) 1/8 NPT
DPC 04/14 and
DPC07/17
DPC 37 and
DPC 47
1.05 "
26.7 mm
0.27 "
6.7 mm
1.85 "
46.9 mm
0.13 "
3.2 mm
0.80 "
20.3 mm
6-32 UNC - 2B x 0.22
(2) holes
D
(both sides)
C
0.53 "
13.3 mm
B
A
1.27 "
32.2 mm
5.43 "
(137.9 mm)
1.60 "
(40.6 mm)
0.49" (12.3 mm)
1/4 - 18 NPT
4.85 "
(123.1 mm)
0.80 "
(20.3 mm)
0.75 "
(19.1 mm)
2.50 "
(63.5 mm)
1.25" (31.8 mm)
0.18" (4.4 mm)
8-32 UNC - 2B 0.30
1.27 "
(32.2 mm)
x
