TABLE IX: LIST OF SUPPORTED TEMPERATURE UNITS OF MEASURE
Number Temperature Units Label Description
1 ˚F degree Fahrenheit
2 ˚C degree Celsius
3 K Kelvin
4 ˚R degree Rankine
NOTE: Program the Measuring Units fi rst because subsequent menus may be
based on the units selected. Once Flow Unit of Measure is changed, the
Totalizer’s Unit of Measure will be automatically updated.
6.4.7 “Submenu User-Defi ned Units”
In addition to conventional fl ow units, user-defi ned fl ow engineering units may be selected.
Use the “Engineering Units and K-Factor” menu to navigate to the “User-Defi ned Units”
menu option. This option enables user defi ned confi guration of any engineering unit required
for process measurement.
The following three parameters are available for this function:
UD Unit volume K-Factor (defi ned in Liters)
UD Unit time base (defi ned in Seconds)
UD Unit use density (units with or without density support)
Before using the User-Defi ned Unit, be sure the proper conversion factor of the new unit,
with respect to one liter, is set. The default entry is 1.00 Liter. Also, proper time-based values
for User-Defi ned Units must be set.
Figure 19 explains by diagram the various upper level display menus.
