6.4.6 Submenu “Units of Measure”
Use the “Units of Measure" Menu to navigate to Measuring Units settings for Mass Flow,
Volumetric Flow, Pressure, and Temperature readings. This option allows confi guration of
the fl ow controller with the desired units of measurement. These are global settings and
determine what appears on all Process Information screens and in all data log records. Units
should be selected to meet your particular metering needs. A total of 44 different massbased
engineering units (Standard, Normal and True Mass) are supported (see Table VI). A total of
15 different volumetric fl ow rate units are supported (see Table VII).
Supported Pressure units of measure are listed in Table VIII, and Supported Temperature
units of measure are listed in Table IX.
TABLE VI: LIST OF SUPPORTED MASS FLOW UNITS OF MEASURE
Number
Mass Flow Rate
Units
Totalizer Volume
Units
Description
STANDARD
1 %FS %s Percent of Full Scale
2 SuL/min SuL Microliters per minute
3 SmL/sec SmL Milliliter per second
4 SmL/min SmL Milliliters per minute
5 SmL/hr SmL Milliliter per hour
6 SL/sec SL Liter per second
7 SL/min SL Liter per minute
8 SL/hr SL Liter per hour
9 SL/day SL Liter per day
10 Sm3/min Sm3 Cubic meter per minute
11 Sm3/hr Sm3 Cubic meter per hour
12 Sm3/day Sm3 Cubic meter per day
13 Sf3/sec Sf3 Cubic feet per second
14 Sf3/min Sf3 Cubic feet per minute
15 Sf3/hr Sf3 Cubic feet per hour
16 Sf3/day Sf3 Cubic feet per day
TRUE MASS
17 gr/sec gr Grams per second
18 gr/min gr Grams per minute
19 gr/hr gr Grams per hour
20 gr/day gr Grams per day
21 kg/min kg Kilograms per minute
22 kg/hr kg Kilograms per hour
23 kg/day kg Kilograms per day
