b) Baud Rate Settings (Tabular entry)
This option determines the device’s Modbus interface speed (Baud rate). It can be set
to one of the following:
1200
2400
4800
9600
19200
38400
57600
115200
By default, the device is shipped from the factory with its baud rate set at 9600.
NOTE: If multiple instruments are connected to the Modbus Master controller
device, they all should have the same baud rate settings as the Master.
c) Modbus Communication Parity (Tabular entry)
This parameter can be set to either None, Odd, or Even. By default, the Parity
parameter is set to None. In real applications, this parameter should follow Parity
settings used in the Modbus Master controller.
d) Modbus Communication Stop Bit (Tabular entry)
This parameter can be set to either One (1) or Two (2). By default, the Stop Bit
parameter is set to 2. In real applications, this parameter should follow Stop Bit
settings used in the Modbus Master controller.
