95
COMMAND
NAME
DESCRIPTION No.
COMMAND SYNTAX
Command Argument 1 Argument 2 Argument 3 Argument 4 Response
Analog
Output
Sets/Reads Instrument Analog Output
settings and alarm status.
Device Analog Output mode: Settings:
0 – 0-5 Vdc
1 – 0-10 Vdc
2 – 4-20 mA
Device Analog Output alarm status:
N – No Alarm (normal operation).
Y – Alarm is On (abnormal conditions
are detected).
16 AO M No Argument
(Returns Current
Analog Output
mode settings)
AOM:<Value>
Example:
AOM:0
<Value>[0-2]
Set new Analog
Output mode
settings
AOM:<Value>
Example:
AOM:1
S No Argument
(Returns Current
Analog Output
alarm status)
AOS:N
Analog
Input
Sets/Reads Instrument Analog Input
settings. Device Analog Input mode
settings:
0 – 0-5 Vdc
1 – 0-10 Vdc
2 – 4-20 mA
Device Analog Input Damping:
0-100 are valid settings
Default settings is 0: no averaging
17 AI M No Argument
(Returns Current
Analog Input
mode settings)
AIM:<Value>
Example:
AIM:0
<Value>[0-2]
Set new Analog
Input mode
settings
AIM:<Value>
Example:
AIM:1
D No Argument
(Returns Current
settings)
AID:0
<Value>[0-100]
Set new Analog
Input damping
settings
AID:0
