50
Recalling the memory data
Confirm that the “Data memory ( data )” parameter is set to “2”.
1 Press and hold the PRINT key until reCall is displayed.
2 Press the PRINT key to enter the memory recall mode. Recall the data in memory using the
following keys
RE-ZERO key To proceed to the next data set.
MODE key To go back to the previous data set.
PRINT key To transmit the current data using the RS-232C interface.
With SAMPLE held down, press the CAL key
To delete the data currently displayed.
Note: Deleting the data will not increase the number of data that can be stored.
CAL key To exit the memory recall mode.
3 Press the CAL key to return to the weighing mode.
Transmitting all memory data at one time
Confirm that the “Serial interface ( 5if )” parameters are set properly. For details, refer to “10.
FUNCTION TABLE” and “17. CONNECTION TO PERIPHERAL EQUIPMENT”.
1 Press and hold the PRINT key until reCall is displayed.
2 Press the SAMPLE key to display out .
3 Press the PRINT key to display Sout no with “no” blinking.
5 Press the RE-ZERO key to display out go with “go” blinking.
6 Press the PRINT key to transmit all data using the RS-232C interface.
7 The balance displays Clear when all data is transmitted. Press the CAL key to return to the
weighing mode.
Deleting all memory data at one time
1 Press and hold the PRINT key until reCall is displayed.
2 Press the SAMPLE key several times to display Clear .
3 Press the PRINT key to display SClr no with “no” blinking.
4 Press the RE-ZERO key to display SClr go with “go” blinking.
5 Press the PRINT key to delete all data
6 The balance displays end , then reCall when all data is deleted.
7 Press the CAL key to return to the weighing mode.
