17. CONNECTION TO PERIPHERAL EQUIPMENT
17-1 Connection to the AD-8121B Printer
Set the following parameters to use the AD-8121B printer.
Function setting Description
dout prt 0-3
Selects a print mode.
dout ap-p 0-2
Selects the polarity for the auto print mode.
dout ap-b 0-2
Selects the auto print difference.
dout pU5e 0,1
Selects data output pause.
5if bp5 2 Factory setting 2400 bps
5if btpr 0 Factory setting 7 bits, Even parity check
5if Crlf 0 Factory setting CR, LF
5if Ct5 0 Factory setting CTS and RTS control, not used
When “MODE 1” or “MODE 2” of the AD-8121B printer is used
dout 5-id 0 Factory setting Does not output the ID number.
dout at-f 0 Factory setting Does not perform auto feed.
5if type 0 Factory setting A&D standard format
When “MODE 3” of the AD-8121B printer is used.
dout 5-id 0、1
Select whether or not the ID number is output.
dout at-f 0、1
Select whether or not auto feed is performed.
5if type 1
DP format
When data is transmitted continuously./When all memory data is transmitted at one
time.
dout pU5e 1
Uses pause.
Note
The printer performs as follows, depending on the data memory setting.
Setting What is printed
data 0
The weighing data
data 2
The weighing data stored in memory
Refer to “11. ID NUMBER AND GLP REPORT” for a print sample.
17-2 Connection to a Computer
The GF series balance is of the DCE type (Data Communication Equipment), which can be
connected to a personal computer using the RS-232C interface.
Before connection, read the personal computer manual thoroughly.
Use a standard DCE cable for connection (cable type: straight-through).
