GF-1200/2000/3000/4000/6100/6000/8000
Note
Please confirm that the AC adapter type is correct
for your local voltage and receptacle type.
2-2 Installing the Balance
Install the balance as follows:
1. Refer to “3. PRECAUTIONS” for installing the balance. Place the balance on a solid weighing
table.
2. GF-200/300/400/600/800/1000
Assemble the breeze break on the balance as shown in the illustration on page 6.
GF-1200/2000/3000/4000/6100/6000/8000
Assemble the breeze ring and weighing pan on the balance as shown in the illustration above.
3. Adjust the leveling feet to level the balance. Confirm it using the bubble spirit level.
4. Confirm that the adapter type is correct for the local voltage and power receptacle type.
5. Connect the AC adapter to the balance. Warm up the balance for at least 30 minutes with
nothing on the weighing pan.
Keys
Weighing pan
Main unit
Breeze ring
Bubble spirit
level
Leveling foot
Display
Windows communication
tools (WinCT)
AC adapter
AC adapter
ID label
Main unit cover
AC adapter plug
AC adapter jack
Grounding
terminal
RS-232C
serial interface
(External input terminal)
Reference card
Pan support
receptor
Main unit
rear side
