AAON CB-024 User Manual

CB Series Feature String Nomenclature
Model Options
:
Unit Feature Options
GEN
MJREV
UNIT SIZE
VLT
COMP
CKTS
1
2
3
4
5
6
7
CB
-
B
-
060
-
3
-
B
-
1
:
B
D
0
0
D
A
0
10
CB Base Model and Features Desc ription
BASE MODEL
SERIES AND GENERATION
CB
REVISION
B = Design Sequence
UNIT SIZE
024 = 24 MBH - 2 Ton - Vertical Discharge
036 = 36 MBH - 3 Ton - Vertical Discharge
048 = 48 MBH - 4 Ton - Vertical Discharge
060 = 60 MBH - 5 Ton - Vertical Discharge
VOLTAGE
1 = 230V/1Φ/60Hz
2 = 230V/3Φ/60Hz
3 = 460V/3Φ/60Hz
4 = 575V/3Φ/60Hz
8 = 208V/3Φ/60Hz
9 = 208V/1Φ/60Hz
COMPRESSOR TYPE
B = R-410A Two Step Scroll Compressor
D = R-410A Variable Capacity Scroll Compressor
F = R-410A Two Step Scroll Compressor with Sound
Blanket
H = R-410A Variable Capacity Scroll Compressor
with Sound Blanket
NUMBER OF CIRCUITS
1 = One Circuit
FEATURE 1: AMBIENT CONTROL
0 = Standard (55°F Ambient)
B = Adjustable Fan Cycling (35°F Ambient)
D = Modulating Fan Pressure Control (35°F
Ambient)
F = Flooded Condenser Ambient Controls (0°F) +
Option B
G = Flooded Condenser Ambient Controls (0°F) +
Option D
FEATURE 2: REFRIGERATION
OPTIONS
0 = Standard - Split System Air Conditioner
A = External Hot Gas Bypass
B = Split System Heat Pump
D = Modulating Hot Gas Reheat
F = Options A + D
G = Options B + D
FEATURE 3: CONTROLS
0 = Standard - Terminal Block
A = Suction Pressure Transducer (F1- Wattmaster
Reheat)
H = Control Circuit Transformer
S = Suction Pressure Transducer (Not F1 -
Wattmaster Controls)
T = Control Circuit Transformer w/ Suction Pressure
Transducer
FEATURE 4: COIL PROTECTION
0 = Standard
A = Polymer E-Coated Coil
FEATURE 5: CABINET OPTIONS
D = Standard – Louvered Panels + 2500 Hour Salt-
Spray Tested Exterior Paint
G = Wire Grille + 2500 Hour Salt-Spray Tested
Exterior Paint
FEATURE 6: WARRANTY
0 = Standard
A = Second to Fifth Year Extended Compressor
Warranty
FEATURE 7: TYPE
0 = Standard
X = Special Pricing Authorization
