It is recommended that the field installed
overcurrent protection or disconnect switch
not be installed on the unit.
Supply voltage must be within the min/max
range shown on the unit nameplate.
Available short circuit current should not
exceed the short circuit current rating
(SCCR) shown on the unit nameplate.
Three phase voltage imbalance will cause
motor overheating and premature failure.
The maximum allowable imbalance is 2.0%.
Voltage imbalance is defined as 100 times
the maximum deviation from the average
voltage divided by the average voltage.
Example:
(221V+230V+227V)/3 = 226V, then
100*(226V-221V)/226V = 2.2%, which
exceeds the allowable imbalance.
Check voltage imbalance at the unit
disconnect switch and at the compressor
terminal. Contact your local power company
for line voltage corrections.
Installing contractor must check for proper
motor rotation and check blower motor
amperage listed on the motor nameplate is
not exceeded.
Wire control signals to the unit’s low
voltage terminal block located in the
controls compartment.
If any factory installed wiring must be
replaced, use a minimum 105°C type AWM
insulated conductors.
Thermostat
If a thermostat is used for unit control,
thermostat should be located on an inside
wall 4-5 feet above the floor where it will
not be subjected to drafts, sun exposure, or
heat from electrical fixtures or appliances.
Follow thermostat manufacturer’s
instructions for general installation
procedure.
Thermostat control wiring size must be large
enough to prevent excess voltage drop and
ensure proper operation.
All external devices must be powered via a
separate external power supply.
Units with the modulating hot gas reheat
dehumidification feature must use a
humidistat or a thermostat with a normally
closed (NC) dehumidification option. The
following thermostats have been approved
for usage with the dehumidification feature,
Robertshaw
®
9825i2 Thermostat
Honeywell VisionPRO
®
IAQ Thermostat
AAON Mini Controller
Three phase voltage imbalance will
cause motor overheating and
premature failure.
