For units equipped with low ambient
refrigerant flood back option being charged
when the ambient temperature is cold:
Once enough charge has been added to get
the evaporator superheat and sub-cooling
values to the correct setting, more charge
may need to be added. If the ambient
temperature is 0°F no more charge is
required. If the ambient temperature is
around 40°F add approximately 40% of the
receiver tank volume.
The unit will have to be checked for proper
operation once the ambient temperature is
above 80°F.
Air Flow
Table 4 - Performance Testing Air Flow Setpoints
Model
Cooling Stage 2
(cfm)
Cooling Stage 1
(cfm)
Heating Stage 2
(cfm)
Heating Stage 1
(cfm)
CB-B-024-*-*-1
885
663.75
885
796.5
CB-B-036-*-*-1
1250
937.5
1250
1125
CB-B-048-*-*-1
1500
1125
1500
1350
CB-B-060-*-*-1
1545
1158.75
1545
1390.5
Before completing startup and
leaving the unit a complete operating
cycle should be observed to verify
that all components are functioning
properly.
CAUTION
