VCCX2 Controller Technical Guide
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
RSMZ 4
Superheat
AI: 206 Current RSMZ 4
Superheat
Temperature
RSMZ 4
EEV
Position
AI: 207 Current RSMZ 4
EEV valve
position
RSMZ 4
Warnings
AI: 208 Current RSMZ 4
Warnings
See RSMZ
Warnings Bits on
pages 134-135.
RSMZ 4
Comp VFD
Alarms 1
AI: 209 Current RSMZ 4
Comp VFD Alarms 1
See RSMZ
Alarms 1 Bits on
pages 134-135.
RSMZ 4
Comp VFD
Alarms 2
AI: 210 Current RSMZ 4
Comp VFD Alarms 2
See RSMZ
Alarms 2 Bits on
pages 134-135.
RSMZ 4
Comp VFD
Drive
Status
AI: 211 Current RSMZ 4
Comp VFD drive status
See RSMZ
Drive Status Bits on
pages 134-135.
RSMZ 4
Comp VFD
Compressor
Current
AI: 212 Current reading in Amps
that the RSMZ 4
compressor is using
RSMZ 4
Discharge
Line Temp
AI: 213 Current RSMZ 4
discharge line
temperature
RSMZ 4
Faults
AI: 214 Current RSMZ 4
Faults
See RSMZ
Faults Bits on pages
134-135.
RSMZ 4
Lockouts
AI: 215 Current RSMZ 4
Lockouts
See RSMZ
Lockouts Bits on
pages 134-135.
RSMZ 5
Condenser
Fan
AI: 216 Current RSMZ 5
Condenser Fan Signal
RSMZ 5
VFD
Comp
Perc
AI: 217 Current RSMZ 5
VFD Compressor
Percentage
RSMZ 5
Discharge
Pressure
AI: 218 Current RSMZ 5
discharge
pressure
RSMZ 5
Suction
Pressure
AI: 219 Current
RSMZ 5 Suction
pressure
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
RSMZ 5
Suction Line
Temp
AI: 220 Current RSMZ 5
Suction Line
Temperature
RSMZ 5
Saturation
Temp
AI: 221 Current RSMZ 5
Saturation
Temperature
RSMZ 5
Superheat
AI: 222 Current RSMZ5
Superheat
temperature
RSMZ 5
EEV
Position
AI: 223 Current RSMZ 5
EEV valve
position
RSMZ 5
Warnings
AI: 224 Current RSMZ 5
Warnings
See RSMZ
Warnings Bits on
pages 134-135.
RSMZ 5
Comp VFD
Alarms 1
AI: 225 Current RSMZ 5
Comp VFD Alarms 1
See RSMZ
Alarms 1 Bits on
pages 134-135.
RSMZ 5
Comp VFD
Alarms 2
AI: 226 Current RSMZ 5
Comp VFD Alarms 2
See RSMZ
Alarms 2 Bits on
pages 134-135.
RSMZ 5
Comp VFD
Drive
Status
AI: 227 Current RSMZ 5
Comp VFD drive status
See RSMZ
Drive Status Bits on
pages 134-135.
RSMZ 5
Compressor
Current
AI: 228 Current reading in Amps
that the RSMZ 5
compressor is using
RSMZ 5
Discharge
Line Temp
AI: 229 Current RSMZ 5
discharge line
temperature
RSMZ 5
Faults
AI: 230 Current RSMZ 5
Faults
See RSMZ
Faults Bits on pages
134-135.
RSMZ 5
Lockouts
AI: 231 Current RSMZ 5
Lockouts
See RSMZ
Lockouts Bits on
pages 134-135.
RSMZ 6
Condenser
Fan
AI: 232 Current RSMZ 6
condenser fan signal
RSMZ 6
Reheat
Valve 1
AI: 233 Current RSMZ 6
Reheat Valve 1
position
APPENDIX C
-
VCCX2 BACnet
®
VCCX2 BACnet
®
Parameters
