VCCX2 Controller Technical Guide
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
RSMZ 6
Discharge
Pressure
AI: 234 Current RSMZ 6
discharge
pressure
RSMZ 6
Suction
Pressure
AI: 235 Current RSMZ 6
Suction Pressure
RSMZ 6
Suction Line
Temp
AI: 236 Current RSMZ 6
Suction Line
Temperature
RSMZ 6
Saturation
Temp
AI: 237 Current RSMZ 6
Saturation
Temperature
RSMZ 6
Superheat
AI: 238 Current RSMZ 6
Superheat
Temperature
RSMZ 6
EEV
Position
AI: 239 Current RSMZ 6
EEV valve
position
RSMZ 6
Suction
Pressure 2
AI: 240 Current RSMZ 6
Suction pressure 2
RSMZ 6
Suction Line
Temp 2
AI: 241 Current RSMZ 6
Suction Line
Temperature 2
RSMZ 6
Saturation
Temp 2
AI: 242 Current RSMZ 6
Saturation
Temperature 2
RSMZ 6
Superheat 2
AI: 243 Current RSMZ 6
Superheat
Temperature 2
RSMZ 6
EEV
Position 2
AI: 244 Current RSMZ 6
EEV valve
position 2
RSMZ 6
Warnings
AI: 245 Current RSMZ 6
Warnings
See RSMZ
Warnings Bits on
pages 134-135.
RSMZ 6
Discharge
Line Temp
AI: 246 Current RSMZ 6
discharge line
temperature
RSMZ 6
Faults
AI: 247 Current RSMZ 6
Faults
See RSMZ
Faults Bits on pages
134-135.
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
RSMZ 6
Lockouts
AI: 248 Current RSMZ 6
Lockouts
See RSMZ
Lockouts Bits on
pages 134-135.
SUB 1
Sub Cool 1
AI: 249 Current Subcooling
Module 1 Sub Cool 1
reading
SUB 1
Sub Cool 2
AI: 254 Current Subcooling
Module 1 Sub Cool 2
reading
SUB 1
Sub Cool 3
AI: 255 Current Subcooling
Module 1 Sub Cool 3
reading
SUB 1
Pressure 1
AI: 256 Current Subcooling
Module 1 liquid line
pressure 1 reading
SUB 1
Pressure 2
AI: 257 Current Subcooling
Module 1 liquid line
pressure 2 reading
SUB 1
Pressure 3
AI: 258 Current Subcooling
Module 1 liquid line
pressure 3 reading
SUB 1
Saturation 1
AI: 259 Subcooling
Module 1 saturation
temperature 1 reading
SUB 1
Saturation 2
AI: 260 Subcooling
Module 1 saturation
temperature 2 reading
SUB 1
Saturation 3
AI: 261 Subcooling
Module 1 saturation
temperature 3 reading
SUB 1
Line Temp 1
AI: 262 Subcooling
Module 1 liquid line
temperature 1 reading
SUB 1
Line Temp 2
AI: 263 Subcooling
Module 1 liquid line
temperature 2 reading
SUB 1
Line Temp 3
AI: 264 Subcooling
Module 1 liquid line
temperature 3 reading
SUB 2
Sub Cool 1
AI: 265 Current Subcooling
Module 2 Sub Cool 1
reading
APPENDIX C
-
VCCX2 BACnet
®
VCCX2 BACnet
®
Parameters
