Code
Fault
Optional Extra Info
Only
Stat
1
Stat
2
Yellow
Offset
23
Payout motor fault
1 = Singulator ( jammed )
255
255
0
2 = Escalator ( jammed )
BCR
255
255
0
2 = Conveyor ( jammed )
CR
255
255
0
3 = Motorised reject
255
255
0
4 = Singulator ( no tach )
255
255
0
5 = Escalator ( no tach )
BCR
255
255
0
5 = Conveyor ( no tachs )
CR
255
255
0
6 = Sing. ( sensor block )
255
10
0
7 = Esc. ( sensor block )
255
11
0
8 = Carousel ( no tachs )
CR
255
255
0
9 = Carousel ( jammed )
CR
255
255
0
10 = Coin rotor – fault
CR
100
103
0
11 = Coin rotor – tachs
CR
100
103
0
12 = Coin rotor – diameter opto missing
CR
100
103
0
13 = Coin rotor – park opto missing
CR
100
103
0
14 = Coin rotor – coin jam
CR
100
101
0
15 = Coin rotor – excessive jam-jogs
CR
100
101
0
16 = Singulator belt broken
BCR
255
255
0
17 = Escalator belt broken
BCR
255
255
0
26
Payout sensor fault
Hopper = 1 to 8 Opto blocked payout
1to8
2
Hopper = 11 to 18 Opto blocked idle
1to8
3
Hopper = 21 to 28 Opto short-circuit idle
1to8
3
Hopper = 31 to 38 Opto short-circuit payout
1to8
3
Hopper = 41 to 48 Max. current exceeded
1to8
4
Hopper = 51 to 58 Bad EEPROM checksum
1to8
4
Hopper = 61 to 68 Power fail on write
1to8
4
27
Level sensor error
1 = Hopper 1
1
4
2 = Hopper 2
2
4
3 = Hopper 3
3
4
4 = Hopper 4
4
4
5 = Hopper 5
5
4
6 = Hopper 6
6
4
7 = Hopper 7
CR
7
4
8 = Hopper 8
CR
8
4
32
Internal comms bad
0 ( parallel interface to validator )
CR
255
255
33
Supply voltage outside
1 = +24V rail
255
255
operating limits
2 = +5V rail
255
255
35
D.C.E. fault
0, 1 = Blocked
?
100
2 = Broken
100
103
40
RAM test fail
0
255
255
