BCR / CR10x Fault Processing
The current Paylink API design only allows for a single byte of error data. The BCR / CR10x devices
provide 3 bytes, and so to allow for this the initial fault report is followed by an additional information
byte. The contents of these two bytes are described here:
This input to this description is a merged list of error codes from the documents:
CR100 TSP182 Issue 0.9.1 and Bulk Coin Recycler TSP151 Issue 3.8
All error codes will always be reported as:
 EventCode = IMHEI_COIN_UNIT_REPORTED_FAULT
 RawEvent = Value from Code column
 Index = BCR Acceptor
In addition, those error codes marked in blue below will be reported with a subsequent event as:
 Event Code = IMHEI_COIN_DISPENSER_REPORTED_FAULT
 RawEvent = Optional Extra Info for Code 26
Optional Extra Info + 100 for Code 27
 Index = Corresponding BCR Hopper
and those error codes marked in Yellow below will be reported with a subsequent event as:
 Event Code = IMHEI_COIN_INTERNAL_PROBLEM
 RawEvent = Value from Last Column + Optional Extra Info
Code
Fault
Optional Extra Info
Only
Stat
1
Stat
2
Yellow
Offset
0
OK (no fault detected)
0
-
0
1
EEPROM checksum corrupted
1 = Coin acceptor checksum error
100
103
2 = Controller checksum error
CR
255
255
2
Fault on inductive coils
1 to 5 = Validation coil
100
103
6 = Singulator belt sensor
( sensor missing )
255
255
7 = Coin return sensor
( sensor missing )
255
255
8 = Singulator belt sensor
( active but no belt move )
255
255
9 = Coin return sensor
( active but no belt move )
255
255
10 = Coin acceptor wake-up
CR
100
103
3
Fault on credit sensor
0
100
103
8
Fault on sorter exit sensors
1 = 4-way sorter
( blocked )
BCR
100
101
2 = 8-way diverter
( blocked )
BCR
100
101
3 = 8-way diverter
( timeout, coin not seen )
BCR
100
104
11 to 18 = Carousel gate
CR
255
255
9
NVRAM checksum corrupted
0
255
255
19
Fault on coin return mechanism
0
100
101
22
Fault on thermistor
0
100
103
