143BusinessPhone – Dialog 4425 IP Vision
Installation
5 Mount screws according to measures and attach the
phone.
max 5,5 mm
3 mm
9-10 mm
min 22 mm
A
max 5,5 mm
6 mm
9-10 mm
min 22 mm
B
Two upper wall distance screws
and spacer(s) measures
Lower wall distance screw
and spacer measures
