System Overview
10 Document Number: D1000092204 B
• The sources port facilitates communication to optional ion sources, such
as the control valve for the DuoSpray™ ion source, or provision of 24 VDC
for the PhotoSpray
®
ion source.
• The AUX I/O outlet allows for communication with necessary peripheral
devices, such as autosamplers or UV detectors.
• A serial port provides a connection point for additional device
communications.
Figure 1-7 I/O panel
Gas Panel
The gas panel houses the gas supply connections and the external connections
for the source exhaust system.
I/O Panel
SERIAL
SOURCES
AUX I/O IEEE-488
