System Overview
The API 3200™ LC/MS/MS system includes a triple quadrupole mass
spectrometer, a Turbo V™ ion source, a computer, and the Analyst
®
software.
Figure 1-1 API 3200™ instrument and bench
WARNING! If you need to move the system, contact an FSE to assist you. Risk of
personal injury or instrument damage.
Note: Before you operate the instrument, make sure you have read the Safety Practices
guide.
Line Adjustment
Transformer
Roughing Pump
Bench
Mass Spectrometer
Front View
Ion Source
